Our
Electric Kilns
Offer for UK-Mainland only
​
All of our kilns are single phase, 230V AC suitable to run from standard UK 13A Wall Sockets. Our Kilns are competitively priced, come with a 1 year warranty and certificate.
​
As a standard the kilns are fitted with a Simple programable temperature only PID Controller, but if requested we are able to install a Ramp Programable Controller.
​
Individually ordered kilns may require higher power and will be fitted with 32A, single phase plug. It is also possible to replace standard hinge used in a given model, for example instead of the wire hinge in ADY-999 a pantograph type as it is fitted in ADY-1150.
KILN PARAMETERS
​
MAINS SUPPLY: 220-250V AC
POWER: 2600W
SENSOR TYPE: K typeTHERMOCOUPLE
MAXIMUM HEATING TEMPERATURE: +1150°C
ESTIMATED HEATING TIME TO +1150°C: 120 MINUTES
DIMENSIONS OF KILN (mm):
width 510 x depth 590 x height x 500
DIMENSIONS OF CHAMBER (mm):
width 230 x depth 395 x height x 195
WEIGHT: 35 kg
ADY 999C
OD (w)x(d)x(h) : 260x350x400 mm
ID (w)x(d)x(h) : 120x300x150 mm
WEIGHT: 16.4 kg​
ADY 999CXL
OD (w)x(d)x(h) :340x520x390 mm
ID (w)x(d)x(h) : 200x400x150 mm
WEIGHT: 20.4 kg​
KILN PARAMETERS
MODEL: ADY-999CXL, CL, C, CXXL
INPUT: 220-250V AC
POWER: up to 2300W
SENSOR TYPE: K – type THERMOCOUPLE
MAXIMUM HEATING TEMPERATURE: +1000°C
ESTIMATED HEATING TIME TO +1000°C: 60 MINUTE
ADY 999CL
OD (w)x(d)x(h) : 340x420x390 mm
ID (w)x(d)x(h) : 200x300x150 mm
WEIGHT: 18.0 kg​
ADY 999CXXL
OD (w)x(d)x(h) : 510x580x500 mm
ID (w)x(d)x(h) : 200x600x150 mm
WEIGHT: 25.3 kg​
The maximum operating temperature is 1250°C, the furnace of this kiln is made of Insulating Firebricks. Kilns are easy to service, replacing the heating element, TC sensor or, adjusting the lid position is simple. For the operator safety, kilns are equipped with a RCBO, Rotary Switch and a Lid Safety Leaf Switch.
The Rotary Switch is used to switch between clay drying and firing modes.
Ramp programable PID Temperature Controller XMTG 8 or 9 series.
​​​​​
OD (w)x(d)x(h) : 510x580x500 mm
ID (w)x(d)x(h) : 190x390x200 mm
​
​
​
​
​
KILN PARAMETERS
​
MAINS SUPPLY: 220-250V AC
CHAMBER MATERIAL: VERMICULATE
INSULATION MATERIAL: CERAMIC FIBER BLANKET & ROCKWOOL
POWER: 4600W
HEATING ELEMENT MATERIAL: 0.8 mm KA1 (FeCrAl A1) wire
SENSOR TYPE: K – type THERMOCOUPLE
APPROXIMATE DIMENTIONS OF KILN (mm):360(w)x1350(d)x370(h)
DIMENTIONS OF CHAMBER (mm): 250(w)1200(d)150(h)
MAXIMUM HEATING TEMPERATURE: +1000°C
CONNECTION: REQUIRED 32A SINGLE PHASE POWER SOCKET
APPOXIMATE WEIGHT: 50 kg
